ND1P802HFG

 Click on the picture to enter the Gallery


8*10/100Mbps PoE ports, 2*10/100/1000Mbps uplink port
 Support IEEE802.3af/at
Support restrain  network  storm, VLAN function
Support Max Transmission distance up to 250m with PoE Power
 All port supported by MDI/MDIX auto flip and self-negotiation
Built-in power supply;
Maximum power of single PoE port: 30 W;
 Maximum PoE power: 120W;
 Adopts store-and-forward architecture;
 Fanless, natural cooling, small,compact and quiet design, suitable for desktop or wall
Support lightning protection 6000V




Power Power Adapter Voltage AC 110V-240V
Consumption 120W(52V2.3A)

Network Connector
Network Port PoE Ethernet Port 1~8 Port : 10/100Mbps
Ethernet port Uplink Port : 10/100/1000Mbps

Transmission Distance
1~8 Port : 100Mbps:0~100m;
10Mbps: 0~250m;
Uplink Port : 0 ~ 100m
Transmission Medium Cat5/5e/6 standard network cable




Network Switch
Network Standard IEEE802.3/802.3u IEEE802.3xIEEE802.ab
Switching Capacity 5.6Gbps
Packet Buffer Memory 1Mbits
Throughput 4.1664Mbit
MAC Table 2K
Packet Forwarding Rate 10Mbps:14880pps/port
100Mbps:148800pps/port
1000Mbps:1488000pps/port

Power Over Ethernet
PoE Standard IEEE 802.3af/at
PoE Power Supply End-Span(1/2+;3/6-)
PoE Power af=15.4W at=30W

RJ45 port


Port Function
Power priority mechanism fast and forward MAC automatic learning and aging IEEE802.3X Full-duplex and mode and backpressure for Half-duplex mode

LED Indicator

LED Indicator
link/ACT.100Mbps;PoE Status Indicator; Power indicator;Extender

Environmental
Working temperature 0℃~55℃
Relative Humidity 20~95%
Storage temperature -20℃~70℃

Mechanical
Dimension (L×W×H) 202mm*140mm*45mm
Color Black
Weight 1.05kg
Stability MTBF >30000h

10ports switch with 8*10/100M bit PoE ports2*10/100/1000M Uplink Port PoE Standard: IEEE 802.3af/at PoE data & power transmission distance 100meters(100Mbps)250meters(10Mbps)
