1、 24*10/100/1000Mbps PoE ports,2*1000M SFP slot
2、 Support IEEE802.3af/at
3、 Support restrain  network  storm, VLAN function
4、 All port supported by MDI/MDIX auto flip and self-negotiation
5、Built-in power supply;
6、 Maximum power of single PoE port: 30 W;
7、Maximum PoE power: 450W;
8、 Adopts store-and-forward architecture;
9、 Fanless, natural cooling, small,compact and quiet design, suitable for desktop or wall
10、Support lightning protection 6000V

Power Power Adapter Voltage AC 110V-240V
Consumption 450W(52V8.65A)
Network Connector
Network Port PoE Ethernet Port 1~24Port : 10/100/1000Mbps
Ethernet port Uplink Port :
Optical port 2*1000M SFP port
Transmission Distance
1~24 Port : 10/100/1000M: 0~ 100m
Uplink Port :
SFP:depend on SFP Module (2km20km40km...)
Transmission Medium Cat5/5e/6 standard network cable
Network Switch
Network Standard IEEE802.3/802.3u IEEE802.3xIEEE802.ab
Switching Capacity 52Gbps
Packet Buffer Memory 1Mbits
Throughput 38.688Mbit
MAC Table 8K
Fording Model Store -and -forward
Data Package length 1518byte
Full Wire Speed Full wire speed transmission under full duplex mode
Packet Forwarding Rate 10Mbps:14880pps/port
Power Over Ethernet
PoE Standard IEEE 802.3af/at
PoE Power Supply End-Span(1/2+;3/6-)
PoE Power af=15.4W at=30W
LED Indicator
LED Indicator
PWR:keep bright
Port power indicator:keep bright
Port Network indicator:Flicker when there is data transmission
Working temperature 0℃~55℃
Relative Humidity 20~95%
Storage temperature -20℃~70℃
Dimension (L×W×H) 440mm*180mm*44mm
Color Black
Weight 3kg
Stability MTBF >30000h
