ND1P803HFGX

 Click on the picture to enter the Gallery
l8*10/100Mbps PoE ports, 2*10/100/1000Mbps uplink port,1 1000M SFP combo
lSupport IEEE802.3af/at
lSupport restrain  network  storm, VLAN function
l Support Max Transmission distance up to 250m with PoE Power
lAll port supported by MDI/MDIX auto flip and self-negotiation
lBuilt-in power supply;
l Maximum power of single PoE port: 30 W;
l Maximum PoE power: 120W;
l Adopts store-and-forward architecture;
l Fanless, natural cooling, small,compact and quiet design, suitable for desktop or wall
l Support lightning protection 6000V
yle="width: 824px; height: 396px;" />
Item Description
Power Power Adapter Voltage AC 110V-240V
Consumption 120W(52V2.3A)



Network Connector
Network Port		 PoE Ethernet Port 1～8 Port : 10/100Mbps
Ethernet port Uplink Port : 10/100/1000Mbps

SFP Port
SFP Port: 1000Mbps

Transmission Distance		 1～8 Port : 100Mbps:0~100m;
10Mbps: 0~250m;
Uplink Port : 0 ~ 100m

SFP: depends on the optical  module(20km...100km）
Transmission Medium Cat5/5e/6 standard network cable




Network Switch		 Network Standard IEEE802.3/802.3u
IEEE802.3xIEEE802.ab
Switching Capacity 5.6Gbps
Packet buffer memory 1Mbits
Throughput 4.1664Mbit
MAC Table 2K

Paket Forwarding Rate		 10Mbps:14880pps/port
100Mbps:148800pps/port
1000Mbps:1488000pps/port

Power Over Ethernet		 PoE Standard IEEE 802.3af/at
PoE Power Supply End-Span(1/2+;3/6-)
PoE Power af=15.4Wat=30W

RJ45 port

Port Function		 Power priority mechanism fast and forward MAC automatic learning and aging IEEE802.3X Full-duplex and mode and backpressure for Half-duplex mode

LED Indicator
LED Indicator		 link/ACT.100Mbps;PoE Status Indicator; Power indicator;Extender

Environmental		 Working temperature 0℃~55℃
Relative Humidity 20~95%
Storage temperature -20℃~70℃

Mechanical		 Dimension (L×W×H) 202mm*140mm*45mm
Color Black
Weight 1.05kg
